Common workflows and use cases for RAPS CLI.

Interactive Shell Mode

For learning and experimentation, use the interactive shell with TAB completion:

# Start interactive mode
raps shell

# Use TAB completion to discover commands
raps> bucket [TAB]
create    delete    get       list

raps> bucket create <BUCKET_KEY>
raps> bucket create my-project

raps> object upload my-project [TAB completion shows file picker]
raps> object upload my-project ./building.rvt

# Exit when done
raps> exit

Benefits of interactive mode:

  • TAB completion for all commands and parameters
  • Parameter hints show required arguments
  • Command history with arrow key navigation
  • Learning-friendly with built-in help

See Interactive Shell for full details.

Upload and Translate a Model

The most common RAPS workflow: upload a CAD file and translate it for viewing.

# 1. Create a bucket (or use existing)
raps bucket create --key my-project --policy persistent --region US

# 2. Upload the model
raps object upload my-project building.rvt

# 3. Get the URN
URN=$(raps object urn my-project building.rvt --output plain)

# 4. Start translation to SVF2
raps translate start "$URN" --format svf2 --wait

# 5. Check the manifest
raps translate manifest "$URN"

Batch Upload Multiple Files

Upload an entire directory of files with parallel processing.

# Upload all DWG files
raps object upload my-bucket ./drawings/*.dwg --batch --parallel --concurrency 10

# Upload with custom keys (preserving folder structure)
for file in ./models/**/*.rvt; do
  relative="${file#./models/}"
  raps object upload my-bucket "$file" --key "$relative"
done

Browse BIM 360/ACC Projects

Navigate through your BIM 360 or ACC project hierarchy.

# Login with 3-legged OAuth
raps auth login

# List all hubs
raps hub list

# Save hub ID for later
HUB_ID="b.12345678-1234-1234-1234-123456789abc"

# List projects
raps project list "$HUB_ID"

# Save project ID
PROJECT_ID="b.proj-123"

# List top-level folders
raps folder list "$PROJECT_ID" --top

# Browse specific folder
FOLDER_ID="urn:adsk.wipprod:fs.folder:abc123"
raps folder list "$PROJECT_ID" "$FOLDER_ID"

Export Data to JSON

Export data for processing with other tools.

# Export bucket list
raps bucket list --output json > buckets.json

# Process with jq
raps bucket list --output json | jq '.[] | select(.policy == "persistent") | .key'

# Export project structure
raps hub list --output json > hubs.json
for hub in $(jq -r '.[].id' hubs.json); do
  raps project list "$hub" --output json >> projects.json
done

CI/CD Pipeline Example

A complete CI/CD workflow for model validation and translation.

# .github/workflows/model-pipeline.yml
name: Model Pipeline

on:
  push:
    paths:
      - 'models/**/*.rvt'

jobs:
  translate:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v4

      - name: Install RAPS
        run: cargo install raps

      - name: Create bucket
        env:
          APS_CLIENT_ID: ${{ secrets.APS_CLIENT_ID }}
          APS_CLIENT_SECRET: ${{ secrets.APS_CLIENT_SECRET }}
        run: |
          BUCKET="ci-${{ github.run_id }}"
          raps bucket create --key "$BUCKET" --policy transient --region US
          echo "BUCKET=$BUCKET" >> $GITHUB_ENV

      - name: Upload and translate models
        env:
          APS_CLIENT_ID: ${{ secrets.APS_CLIENT_ID }}
          APS_CLIENT_SECRET: ${{ secrets.APS_CLIENT_SECRET }}
        run: |
          for file in models/**/*.rvt; do
            name=$(basename "$file")
            raps object upload "$BUCKET" "$file"
            URN=$(raps object urn "$BUCKET" "$name" --output plain)
            raps translate start "$URN" --format svf2 --wait
          done

Generate Signed URLs for Sharing

Create temporary download links for sharing files.

# Generate a 60-minute URL
raps object signed-url my-bucket model.rvt --minutes 60

# Generate URLs for all files in a bucket
for obj in $(raps object list my-bucket --output json | jq -r '.[].key'); do
  echo "$obj:"
  raps object signed-url my-bucket "$obj" --minutes 120
done

Webhook Setup

Set up webhooks to receive notifications about events.

# Create a webhook for translation events
raps webhook create \
  --event "extraction.finished" \
  --callback "https://myapp.com/webhooks/translation" \
  --scope "data:read"

# List active webhooks
raps webhook list

# Delete a webhook
raps webhook delete webhook-id-here

Design Automation

Run Design Automation work items for CAD processing.

# List available engines
raps da engine list

# Create an activity
raps da activity create \
  --id "ExtractData" \
  --engine "Autodesk.Revit+2024" \
  --command "$(Get-Content ./appbundle/command.json)"

# Submit a work item
raps da workitem create \
  --activity "my-nickname.ExtractData+prod" \
  --input "urn:adsk..." \
  --output "https://my-bucket.s3.amazonaws.com/output"

# Monitor work item
raps da workitem status work-item-id --wait

Reality Capture

Create photogrammetry models from photos.

# Create a photoscene
raps rc photoscene create --name "Site Survey" --type "object"

# Upload photos
raps rc photoscene upload photoscene-id ./photos/*.jpg

# Start processing
raps rc photoscene process photoscene-id

# Check progress
raps rc photoscene status photoscene-id --wait

# Download results
raps rc photoscene download photoscene-id --output ./output/
