Authentication Commands

RAPS🌼RAPSRust CLI for Autodesk Platform Services.View in glossary supports both 2-legged (client credentials🤖2-legged authServer-to-server authentication without user context.View in glossary) and 3-legged (authorization code👤3-legged authUser-authorized authentication with browser login.View in glossary) OAuth🔐OAuthIndustry-standard authorization protocol used by APS.View in glossary flows.

Commands Overview

raps auth test

Test 2-legged OAuth authentication using your Client ID and Client Secret🔒SecretEncrypted sensitive configuration value.View in glossary.

$ raps auth test
✓ Authentication successful!
  Token expires in: 3599 seconds

Requirements:

• APS_CLIENT_ID environment variable🌍Environment VariableConfiguration value passed to applications.View in glossary
• APS_CLIENT_SECRET environment variable

raps auth login

Login with 3-legged OAuth. Supports multiple methods.

raps auth login [--default] [--preset PRESET] [--device] [--token <token>]

Options:

• -d, --default: Use default scopes without prompting
• -p, --preset <PRESET>: Use a preset scope collection (New in v4.6)
• --device: Use device code flow (for headless/server environments)
• --token <token>: Provide access token directly (for CI/CD🔁CI/CDAutomated build, test, and deployment pipelines.View in glossary)

Available presets:

Browser-based login (default):

$ raps auth login
Opening browser for authentication...
Select scopes:
  [x] data:read
  [x] data:write
  [x] data:create
  [x] account:read
  [x] user:read
  [x] viewables:read

✓ Login successful!
  User: john.doe@example.com

Device code flow (headless): Updated in v5.1

$ raps auth login --device

Device Authorization
──────────────────────────────────────────────────
  Go to: https://rapscli.xyz/device
  Enter code: ABCD-1234
──────────────────────────────────────────────────
Waiting for authorization...
OK Authorization successful!

Open rapscli.xyz/device on any device (phone, laptop, another machine), enter the short code, and authorize with your Autodesk account. The CLI💻CLIText-based interface for running commands.View in glossary polls automatically and completes login once you approve. No local browser required — works in SSH sessions, containers, and MCP🧠MCPProtocol for AI assistant tool integration.View in glossary servers.

Preset scopes (v4.6+):

# Full access
$ raps auth login -p all

# Read-only access for dashboards
$ raps auth login -p viewer

# Design Automation workflows
$ raps auth login --preset automation

Token-based login (CI/CD):

$ raps auth login --token "eyJhbGc..." --expires-in 3600
✓ Token validated for user: user@example.com

raps auth status

Show current authentication status.

$ raps auth status
Authentication Status
────────────────────────────────────────
  2-legged (Client Credentials): ✓ Available
  3-legged (User Login): ✓ Logged in
    Token: abcd...wxyz
    Expires in: 1h 30m

raps auth inspect

Inspect the current access token for scope, expiry, and metadata.

$ raps auth inspect
Token Information:
────────────────────────────────────────────────────────────
  Valid: ✓ Yes
  Expires At: 2024-01-15 15:30:00 UTC
  Expires In: 45 minutes

  Scopes:
    • data:read
    • data:write
    • data:create
────────────────────────────────────────────────────────────

With expiry warning:

$ raps auth inspect --warn-expiry 3600
⚠ WARNING: Token expires in less than 1 hour!

Authentication Types

2-Legged OAuth (Client Credentials)

Used for server-to-server operations without user context.

Use for:

• Uploading files to OSS
• Creating buckets
• Starting translations
• Managing webhooks🪝WebhooksEvent notifications sent to your application.View in glossary
• Design Automation🤖AutomationReplacing manual processes with software.View in glossary

3-Legged OAuth (Authorization Code)

Used for operations requiring user context.

Use for:

• Accessing BIM 360🔵BIM 360Legacy Autodesk construction platform (predecessor to ACC).View in glossary/ACC🏗️ACCAutodesk's construction management platform.View in glossary hubs and projects
• Browsing folders and items
• Managing issues
• User-specific data

Token Management (v3.7.0+)

RAPS automatically:

• Stores tokens securely using OS keychain🔑KeychainSecure OS storage for credentials.View in glossary (default) or file storage
• Refreshes tokens when they expire
• Uses the appropriate token type for each operation

Secure Token Storage (Default):

• Windows: Windows Credential Manager
• macOS: macOS Keychain
• Linux: Secret Service (gnome-keyring, kwallet)

Fallback File Storage:

• Windows: %APPDATA%\raps\tokens.json
• macOS: ~/Library/Application Support/raps/tokens.json
• Linux: ~/.local/share/raps/tokens.json

🔐 Security: Keychain storage encrypts tokens. File storage stores tokens in plaintext and should only be used in secure environments.

Troubleshooting

”Authentication failed” error

1. Verify APS_CLIENT_ID and APS_CLIENT_SECRET are set correctly
2. Check your APS☁️APSAutodesk Platform Services - cloud APIs for CAD/BIM automation.View in glossary application is active in the Developer Portal
3. Ensure credentials haven’t been rotated

”Callback URL mismatch” error

Verify APS_CALLBACK_URL matches your APS application configuration⚙️ConfigurationSettings controlling application behavior.View in glossary.

”Token expired” error

Try logging out and back in:

raps auth logout && raps auth login
