MCP Server: Talk to Your Model

The raps mcp command▶️CommandInstruction executed by a CLI tool.View in glossary starts a Model Context Protocol🧠MCPProtocol for AI assistant tool integration.View in glossary (MCP) server, enabling AI assistants to interact with Autodesk Platform Services☁️APSAutodesk Platform Services - cloud APIs for CAD/BIM automation.View in glossary through natural language.

New in v3.0.0 — The MCP server is a major feature addition. Expanded in v4.1.0 — Now with admin bulk operations, issues, RFIs, and ACC🏗️ACCAutodesk's construction management platform.View in glossary extended features. Improved in v4.1.1 — Server starts without credentials and provides interactive setup guidance. Enhanced in v4.4.0 — Now with 51 tools including folder permissions, operation lifecycle, and full CRUD for ACC modules. Expanded in v4.5.0 — Now with 72 tools: custom API🔌APIInterface for software components to communicate.View in glossary calls, portfolio reports, templates, webhooks🪝WebhooksEvent notifications sent to your application.View in glossary, Design Automation🤖Design AutomationRun Autodesk desktop apps in the cloud.View in glossary, Reality Capture, and more. Expanded in v4.11.0 — Now with 101 tools: project📁ProjectContainer for folders and files within a hub.View in glossary CRUD (update, archive), user management (remove, update), template convert, and comprehensive coverage of all APS APIs. Expanded in v5.1.0 — Now with 111 tools for broader APS and orchestration coverage. Expanded in v5.6.0 — Now with 114 tools including skill management, pipeline⛓️PipelineAutomated sequence of build/test/deploy steps.View in glossary operations, and swarm orchestration.

From “Chat with PDF” to “Chat with Tools”

We are moving past the era of “Chat with PDF.” The next frontier is Chat with Tools.

If you have ever tried to paste a 500MB JSON📋JSONStandard data interchange format.View in glossary metadata extract from a Revit🏠RevitAutodesk's BIM software for architecture and construction.View in glossary model into ChatGPT, you know the pain: “Message too long.” RAG (Retrieval-Augmented Generation) helps, but it is static. It can’t query the current state of a model or trigger an action.

Enter the Model Context Protocol (MCP).

What is MCP?

The Model Context Protocol is an open standard that allows AI assistants to use external tools. Instead of dumping data into the context window, the LLM has access to a live toolkit.

With RAPS🌼RAPSRust CLI for Autodesk Platform Services.View in glossary MCP server, you can ask your AI assistant to:

• Find specific BIM🏛️BIMIntelligent 3D model-based design for buildings.View in glossary elements by properties (“all ‘Basic Wall’ instances over 100m²”)
• Create and manage buckets dynamically
• Upload files and start translations
• Browse BIM 360🔵BIM 360Legacy Autodesk construction platform (predecessor to ACC).View in glossary/ACC projects in real-time
• Check translation⚙️Translation JobBackground process converting CAD files to viewable formats.View in glossary status and retrieve results
• Query live model metadata without size limits
• Bulk manage users across multiple ACC/BIM 360 projects
• Track and manage issues in construction projects
• Query RFIs, assets, submittals, and checklists
• Navigate folders and items with full permission control

This bridges the gap between the rigid, complex data structures of BIM and the natural language interface of AI.

Quick Start

# Start the MCP server
raps mcp

The server runs in stdio mode, listening for MCP requests from AI assistants.

No credentials required to start. The server starts even without APS credentials configured. When you ask your AI assistant about authentication status, it will provide step🔧STEPISO standard for 3D CAD data exchange.View in glossary-by-step setup instructions. This means you can add RAPS to your AI assistant first, then get guided through the setup process interactively.

Configuration

Claude Desktop

Add to your Claude configuration⚙️ConfigurationSettings controlling application behavior.View in glossary file:

macOS: ~/Library/Application Support/Claude/claude_desktop_config.json Windows: %APPDATA%\Claude\claude_desktop_config.json Linux: ~/.config/claude/claude_desktop_config.json

Minimal setup (get guided later):

{
  "mcpServers": {
    "raps": {
      "command": "raps",
      "args": ["mcp"]
    }
  }
}

After adding this, restart Claude and ask “What’s my auth status?” — RAPS will guide you through credential setup.

Full setup (with credentials):

{
  "mcpServers": {
    "raps": {
      "command": "raps",
      "args": ["mcp"],
      "env": {
        "APS_CLIENT_ID": "your_client_id",
        "APS_CLIENT_SECRET": "your_client_secret"
      }
    }
  }
}

Cursor IDE

Add to .cursor/mcp.json in your project:

{
  "mcpServers": {
    "raps": {
      "command": "raps",
      "args": ["mcp"]
    }
  }
}

Note: Cursor uses environment variables from your shell🖥️TerminalApplication for running command-line programs.View in glossary, so ensure APS_CLIENT_ID and APS_CLIENT_SECRET are set.

Available Tools

The RAPS MCP server exposes 114 tools organized by functionality:

Authentication

OSS Buckets

OSS Objects

Model Derivative

Data Management

Project Management

Admin Bulk Operations

Issues

RFIs

ACC Extended

Issue Comments

Checklist Templates

Custom API

Portfolio Reports

Template Management

Webhooks

Design Automation

Reality Capture

How It Works: Live Tool Execution

Instead of dumping data into the context window, the LLM has access to a toolkit. When you ask a question, the flow looks like this:

1. You: “Find all ‘Basic Wall’ instances in the ‘Hospital.rvt📊RVTRevit's native file format.View in glossary’ file that are over 100m².”
2. LLM: Thinking… I need to inspect the model metadata.
3. LLM (Action): Calls raps model:query --file Hospital.rvt --category Walls
4. RAPS: Returns a filtered JSON snippet.
5. LLM (Response): “I found 12 walls matching your criteria. Here are their IDs…”

You don’t need to write SQL or complex filter queries. You just ask. The AI translates your natural language into the appropriate RAPS commands.

Example Conversations

First-time setup (no credentials)

You: What’s my authentication status?

AI: Let me check your authentication status.

Setup Required

No APS credentials are configured yet. Here’s how to get started:

1. Go to https://aps.autodesk.com and create a free account
2. Create a new application to get your Client ID and Secret🔒SecretEncrypted sensitive configuration value.View in glossary
3. Add credentials to your MCP configuration:

{
  "mcpServers": {
    "raps": {
      "command": "raps",
      "args": ["mcp"],
      "env": {
        "APS_CLIENT_ID": "your_client_id",
        "APS_CLIENT_SECRET": "your_client_secret"
      }
    }
  }
}

After adding credentials, restart your AI assistant to apply the changes.

Checking authentication status (with credentials)

You: What’s my current authentication status?

AI: Let me check your authentication status.

Authentication Status:

• 2-legged OAuth🔐OAuthIndustry-standard authorization protocol used by APS.View in glossary: ✓ Valid
• 3-legged OAuth: Not logged in

Tool Availability:

• ✓ OSS📦OSSAPS cloud storage for files and models.View in glossary (bucket_, object_) - available
• ✓ Derivative📤DerivativeAny output generated from model translation.View in glossary (translate_*) - available
• ✗ Data Management📂Data ManagementAPS service for accessing files in ACC, BIM 360, and Fusion.View in glossary (hub_, project_) - requires 3-legged auth

To access BIM 360/ACC data, you need to log in with your Autodesk account. Run raps auth login in your terminal.

Creating a bucket

You: Create a new persistent bucket in the US region called “my-project-files”

AI: I’ll create that bucket for you.

✓ Created bucket ‘my-project-files’ with persistent retention in US region.

Checking buckets

You: What buckets do I have access to?

AI: Let me check your accessible buckets.

You have 3 buckets:

• my-project-files (persistent, US)
• temp-uploads (transient, US)
• eu-data (persistent, EMEA)

Advanced model querying

You: Find all steel beams in the hospital model that are longer than 10 meters and show me their material properties

AI: Let me query the model metadata for you.

Found 47 steel beams over 10 meters:

• W12x45 beams: 12 instances (Grade 50 steel)
• W14x30 beams: 23 instances (Grade 36 steel)
• W16x67 beams: 12 instances (Grade 50 steel)

All beams have fire rating of 2 hours. Would you like the complete material specifications?

Translation workflow

You: Start translating the file “building.rvt” in bucket “my-project-files” to SVF2🚀SVF2Current APS viewing format (improved performance).View in glossary format

AI: I’ll start the translation. First, let me get the URN for that file.

✓ Translation started. The file is being converted to SVF2 format. You can check the status by asking me about it.

Bulk user management

You: Add john.smith@company.com to all projects that start with “2026-” as a Project Admin

AI: I’ll add that user to the matching projects. Let me first find all projects with the “2026-” prefix.

Found 8 projects matching “2026-*”:

• 2026-Hospital-Phase1
• 2026-Hospital-Phase2
• 2026-Office-Tower … and 5 more

✓ Started bulk add operation. User will be added to all 8 projects as Project Admin. Operation ID: op_abc123. You can ask me for status updates.

Managing issues

You: Create an issue for the Hospital project about the missing fire door schedule

AI: I’ll create that issue for you.

✓ Created issue #47: “Missing fire door schedule”

• Project: 2026-Hospital-Phase1
• Type: Design
• Status: Open
• Assignee: Unassigned

Would you like me to assign it to someone?

Querying RFIs

You: Show me all open RFIs in the Office Tower project

AI: Let me query the RFIs for that project.

Found 3 open RFIs:

• RFI-012: “Clarification on structural beam dimensions” (Due: Jan 20)
• RFI-015: “MEP coordination at Level 5” (Due: Jan 22)
• RFI-018: “Curtain wall detail at entrance” (Due: Jan 25)

Would you like details on any of these?

Architecture

The MCP server reuses all existing RAPS API clients:

┌─────────────────┐     ┌──────────────────┐
│   AI Assistant  │────▶│  RAPS MCP Server │
│  (Claude, etc.) │◀────│   raps mcp       │
└─────────────────┘     └────────┬─────────┘
                                 │
     ┌───────────┬───────────┬───┴───┬───────────┬───────────┐
     │           │           │       │           │           │
┌────▼────┐ ┌────▼────┐ ┌────▼───┐ ┌─▼──┐ ┌─────▼─────┐ ┌────▼────┐
│  Auth   │ │   OSS   │ │ Deriv  │ │ DM │ │   Admin   │ │   ACC   │
│ Client  │ │ Client  │ │ Client │ │    │ │  Clients  │ │ Clients │
└────┬────┘ └────┬────┘ └────┬───┘ └──┬─┘ └─────┬─────┘ └────┬────┘
     │           │           │        │         │            │
     └───────────┴───────────┴────┬───┴─────────┴────────────┘
                                  │
                           ┌──────▼──────┐
                           │   APS APIs  │
                           └─────────────┘

The Admin and ACC clients are created on-demand for each request to support bulk operations and project-specific APIs.

Limitations

• No file uploads: MCP currently doesn’t support binary file transfer. Use CLI💻CLIText-based interface for running commands.View in glossary for uploads.
• 3-legged auth requires CLI: While MCP tools can check auth status and provide guidance, the actual 3-legged login must be done via raps auth login in a terminal with browser access.
• Stdio transport: Server must be started by the AI client, not as a daemon.

Debugging

Enable verbose logging:

RUST_LOG=debug raps mcp

Check server connectivity:

echo '{"jsonrpc":"2.0","method":"initialize","params":{},"id":1}' | raps mcp
